| Pricing: | Ex VAT | Inc VAT |
| 1+ | £0.30 (excl. VAT) | £0.36 (excl. VAT) |
| 10+ | £0.22 (excl. VAT) | £0.26 (excl. VAT) |
| 100+ | £0.21 (excl. VAT) | £0.25 (excl. VAT) |
| 500+ | £0.20 (excl. VAT) | £0.24 (excl. VAT) |
Available while stocks last - 878 left!
This bright pink LED has a wide viewing angle and a slightly shorter body than most 5mm LEDs. The LED is ideal for many applications and the wide viewing angle makes it also ideal for use in textiles projects.
| Forward voltage drop: | 3.1 V |
| Viewing angle: | 100 degrees |
| Max forward current: | 30 mA |
| Luminous intensity: | 700 mCd (@20mA) |
| Lens types: | Water clear |
| Attribute | Value |
|---|---|
| Forward voltage drop | 3.1V. |
| Viewing angle | 100 degrees. |
| Typical forward current | 20 mA. |
| Max forward current | 25 mA. |
| Luminous intensity | 700 mCd (@20mA). |
| Lens types | Water Clear. |
Learn how to add three standard LEDs to a bag using conductive thread in our easy to follow tutorial.
